Plastic Coated Rock Baskets Wire Mesh Chicken Wire With Small Holes
Aluminum magnesium alloys gabion hexagonal-wire-mesh small hole
Gabion Wire Mesh Introduction:
Gabion wire mesh, also known as gabion mesh, gabion mesh in China
is generally known as ecological green grid, in foreign countries,
this product is made into a structure called "Gabion" box.
Gabion net is a transliteration of the word "gabion", in the
Concise English Dictionary, the explanation is: strip basket, metal
basket.
Gabion Wire Mesh specificaiton:
| GABION MESH |
| Opening (mm) | Wire Diameter (mm) | Strands | Sizes |
| 60 x 80 | 2.0-2.8 | 3 | 2m x 1m x 1m,
3m x 1m x 1m,
4m x 1m x 1m,
2m x 1m x 0.5m,
4m x 1m x 0.5m,
Or as request |
| 80 x 100 | 2.0-3.2 | 3 |
| 80 x 120 | 2.0-3.2 | 3 |
| 100 x 120 | 2.0-3.4 | 3 |
| 100 x 150 | 2.0-3.4 | 3 |
| 120 x 150 | 2.0-4.0 | 3 |
| Hot dip galvanized gabion box |
| Size(m) | Mesh size(cm) | Diameter(mm)
selvage wire/mesh wire/tie wire |
2x1x1
2x1x0.5 | 8x10
10x12 | 3.4/2.7/2.2
3.9/3.0/2.2
3.9/2.7/2.2 |
The wire of the stone cage net is the main body of the wire
generally 2.0-4.0mm, the diameter of the edge is greater than the
diameter of the wire, is woven or wound fixed in the direction of
the length of the wire;
The end wire diameter is larger than the wire diameter, is woven or
wound fixed on the edge of the width of the grid, the end wire is
generally the same as the side wire.
The mesh of the stone cage net is formed by mechanical stranded
hexagonal hole, the general mesh is 60*80, 80*100, 100*120,
120*150mm.
Gabion wire mesh various characteristics:
(1) the economy.
Just put the stone into the cage and seal it.
(2) the construction is simple and does not require special
technology.
(3) have a strong ability to resist natural damage and the impact
of adverse climate.
(4) can withstand a large range of deformation, but still does not
collapse.
(5) the silt between the cracks of the cage stone is conducive to
the production of plants, and can be fused into one with the
surrounding natural environment.
(6) It has good permeability and can prevent damage caused by
hydrostatic force.
(7) Save transportation costs.
It can be folded to transport and assembled on the site.
(8) fast progress, conducive to the construction period: can be
multi-group construction at the same time, parallel, flow
operation.
Gabion wire mesh application:
One, control and guide the river and flood: gabion mesh can make
the riverbed river bank to get natural protection, effectively
prevent the flow of water scour the riverbank damage, causing
flooding, leading to a lot of loss of life and property, a lot of
soil erosion.
Two, channels, canals, riverbed: natural river transformation and
artificial channel excavation, gabion mesh can play an effective
optimal protection on the riverbank or riverbed, it can also
control the flow of water, prevent water loss, especially in
environmental protection and water quality maintenance, with
optimal effect.
Three, revetment slope: stone cage gabion mesh structure
application and the river shore and slope foot protection is the
most successful case, it gives full play to the advantages of
ecological grid, to achieve the ideal effect that other methods can
not achieve.
