Q235 Skid Proof Galvanised Driveway Grates Light Structure 32x5mm
Q235 Hot Dip Galvanized Steel Structure Skid Proof Steel Driveway
Grates Grating
Steel Driveway Grates Grating Introduction
Steel grid plate is also called steel grid plate, grid plate, is
made of flat steel in accordance with a certain distance and cross
bar arrangement, and welded into a kind of steel products with a
square grid in the middle, mainly used to do the ditch cover plate,
steel structure platform plate, steel ladder step plate, etc.
The bar is generally made of twisted square steel.
Production method of steel grid plate: steel grid plate is made of
load flat steel and horizontal bar according to a certain distance
by adopting 200 tons of hydraulic resistance welding automation
equipment welding into the original plate, after cutting, opening,
edge packaging and other processes from customer requirements of
the product.
Load flat steel spacing: the center distance between two adjacent
load flat steel, commonly used 30,40 and 50 and other kinds.
Bar spacing: the center spacing of two adjacent bars is usually
50,76,80,100, etc., can be produced according to customer
requirements, according to customer requirements of various types
of steel grid plate.
Steel Driveway Grates Grating Specifications
item | value |
Warranty | 2 years |
After-sale Service | Online technical support |
Chemical Composition | steel |
Alloy Or Not | Is Alloy |
Secondary Or Not | Non-secondary |
Project Solution Capability | graphic design |
Application | Outdoor |
Design Style | Industrial |
Place of Origin | China |
Brand Name | Rising |
Model Number | customzied |
Product name | Steel Grating |
Type | Plain Bar Grating |
Application | Industry,walkway,,catwalk |
Surface treatment | Untreated |
Bearing bar | 32x5 |
Bearing bar pitch | 30mm |
Cross bar | 6*6mm |
Cross bar pitch | 100mm |
Size | 5850mmx995mm |
Usage | Platform |
Steel Driveway Grates Grating Application:
Widely used in petroleum chemical industry, tobacco industry,
electricity, water, sewage disposal, port terminals, building
decoration, shipbuilding, self-contained parking lot, municipal
engineering, environmental sanitation engineering areas such as the
platform, walkway, pier, trench cover, manhole covers, ladders,
fences, stadium, exhibition center, large commercial, station,
wharf, airport and other industrial and civil construction of
condole top, etc.
Steel Driveway Grates Grating Advantages:
1: high strength, light structure
2: strong anti-corrosion ability, durable
3: beautiful appearance, bright surface
4: no dirt, no rain and snow, no water, self-cleaning, easy to
maintain
5: ventilation, lighting, heat dissipation, anti-skid,
explosion-proof good
6: easy to install his folding unloading
Production Process:
Pressure welding steel grid plate is made of load flat steel and
cross bar according to a certain distance by adopting 200 tons of
hydraulic resistance welding automation equipment welding into the
original plate, after cutting, opening, wrapping and other
processes and products customer requirements.
Load flat steel spacing: the center distance between two adjacent
load flat steel, commonly used 30MM, 40MM and 60MM three.
Rod spacing: the center spacing of two adjacent bars is usually
50MM, 100MM, two kinds
Installation Method:
In order to prevent the risk of falling, the installation of the
steel grid plate should be fixed by welding as far as possible.
The steel grid plate shall be installed in accordance with the
steel structure plate. After installation, it shall not be moved
laterally or separated from the supporting frame. The supporting
length at both ends of the steel grid plate bearing the flat steel
direction on the supporting frame shall not be less than 25 mm for
each section.
Platform steel grille plates that require removable and detachable
are secured by the mounting fixture of the steel grille plates.
Prevent any shift of the member;
The requirements of the buyer can be supplied by the manufacturer.
In addition to the installation clip made of stainless steel
material, the installation clip made of carbon steel is treated by
hot dip galvanizing. It is suggested that the bolts used for the
installation clip are treated by hot dip galvanizing.
